Ferrum Hypsos Dual Output
SHIPPING IN MID-JUNE 2024
Ferrum Hypsos
HYPSOS defines a brand new category of a hifi products. It’s not a simple power supply but an audio component of its own – an equally (or even more) important part of a setup as any other. HYPSOS offers a selection of unique features and even accounts for future software improvements – the device is software controlled with as few hardware dependent elements as possible. The most important features are:
Hybrid Power System
Linear/switching hybrid design to get the advantages from both techniques - low ripple and noise as well as fast transient response and high efficiency.
Distinct user levels
Using pre-configured settings from the list of supported devices or setting custom parameters manually. Wide continuous ouput voltage range of 5-30V with up to 6A of current delivered to the load. HYPSOS is as universal a device as it gets.
Sweet Spot Tuning (SST)
Possibility to fine tune the output voltage for the best sound. The voltage level can be safely adjusted on the fly to allow easy comparison testing.
4T Sensing Design (4TSD)
Ensuring the exact voltage level precisely at the point of the powered device DC input terminal - special cable design and feedback to ensure flat voltage at every moment. This technique eliminates the harmful effects of the cable's resistance effectively improving transient response.
Advanced Automation
Compatibility with Apple TV remote, Trigger in/out connector; possibility to automate power-up of the devices with standby mode even without dedicated trigger connection.
Extremely safe to use
Automatic Transformer Voltage Adjust (ATVA), Electronic Output Voltage Polarity Switch and overvoltage, current limit and short protection. Settings lock to prevent accidental change of the parameters.
Detailed and revealing yet unfatiguing sound
Makes your current audio setup perform to its potential. Tweak the sound modifying the voltage level on the fly and use the preferred combination of the 4-Terminal Sensing and Spread Spectrum Mode settings.
Specifications Ferrum HYPSOS Dual Output hybrid power system:
- Power input: 110-120 V AC & 220-240 V AC / 50-60 Hz (EU/US)
- 100 V AC / 50-60 Hz (JP)
- Mains: IEC C14 power inlet, fuse holder, power on/off, two-stage EMI filter
- Mains cable: EU, UK, AU or US
- DC out cable: 5.5 x 2.5 mm or 5.5 x 2.1 mm DC plug
Voltage, current and power specifications showed below are for both outputs combined. Same voltage is shared on both outputs. Current and power are combined from both outputs. 4TSD functionality is only active on the main output.
- DC outp. voltage range: 5-30 V
- Max. cont. outp. power: 60 W
- Max. cont. outp. current: 6 A
- Primary winding fuse: IEC 5x20 mm, 250 V 3.15 A, slow-blow (JP)
- 250 V 2 A, slow-blow (EU/US)
- Power consumption: @ 230 V AC / 50 Hz and 12 V DC out:
- no load (idle) - 6 VA, ~ 80 W load – 133.9 VA
- Dimensions (W x D x H): 21.7 x 20.6 x 5 cm / 8.6 x 8.1 x 2 inch (without knob, feet and connectors)
- Net weight: 3.05 kg / 6.72 lbs
